Slim
Exposed part for single-lever bath shower mixer SLIM_SM014200
Model
SM014200
Exposed part for single-lever bath shower mixer,handshower holder on column,Brass minimalistic one spray handshower,150 cm smooth SUPREME Flexible Hose,for items ZA004510
Available Finishings
Technologies
EcoStop
EcoStop feature limits water flow to approximately 50% of maximum output with one point of resistance on setting. Push slightly past the middle stop only when full water output is required. This will save water up to 50%.
Characteristics
Cartridge Spare Parts: ZZ95409000
Cartridge Name: 35 mm Cartridge
Installation: Concealed
Waterflow
SM014200
| Pressure | Shower(l/min) | Bath(l/min) |
|---|---|---|
| 1 Bar | 6 | 8.8 |
| 2 Bar | 8.4 | 12.9 |
| 3 Bar | 10.4 | 16 |
| 4 Bar | 12.1 | 18.6 |
| 5 Bar | 13.6 | 20.7 |
Concealed Parts
Cconcealed partsparts required for installation
